Gigabit Poe Splitter Power Over Ethernet Adapter

Power-over-Ethernet (PoE) eliminates the need to run DC power to other devices on a wired LAN. Using a Power-over-Ethernet system, installers need to run only a single Category 5 Ethernet cable that carries both power and data to each device. This allows greater flexibility in the locating of network devices and, in many cases, significantly decreases installation costs.

There are two system components in PoE - the PSE (Power Sourcing Equipment) and the PD (Powered Device). The IEEE 802.3af/at specification defines PSE as a device that inserts power onto an Ethernet cable. The PSE may be located at the switch (End-span configuration). or it may be a separate device located between the switch and the PD (Mid-span configuration). The PD is the natural termination of this link, receiving the power, and could be an IP phone, a WLAN access point, or any other IP device that requires power. The current is transmitted over two of the four twisted pairs of wires in a Category-5 cable.

The PoE Splitter splits the 48VDC over the RJ45 Ethernet cable into 5V/9V/12V/18VDC power output. Support PoE applications in Gigabit Ethernet environments.

The modules compliant with IEEE 802.3af/at power classification and support PSE Alternative A and Alternative B connections. Maximum power output can reach 25W. Tiny size, 78mm (L) x 73mm (W) X 28mm (H), wide input voltage range, 36Vdc to 57Vdc and less external components needed one output decoupling capacitor.

²  Complies with IEEE802.3af/at.

²  DC port: 5.5x2.1mm

²  Support PoE applications in Gi gabit Ethernet environments.

²  Auto-Sensing Algorithm enables taking power from IEEE802.3af/at PSE.

²  Splits the 48VDC power over RJ45 Ethernet cable into different DC output.

²  Support wide input voltage range 36Vdc to 57Vdc.

²  Maximum power output up to 25W.

²  Adjustable output 5VDC,9VDC,12VDC,18VDC.

²  Thermal cut off.

²  Short circuit protection.

²  High efficiency DC/DC converter.

²  LED indicators for power input indication.

²  Plug-and-Play.

Item

Description

Ports

1 10/100/1000M RJ45 PoE Port (DATA + POWER IN)

1 10/100/1000M RJ45 LAN Port (Only DATA)

1 DC Jack (DC OUT)

Network Media

10Mbps: Cat 3,4,5 Unshielded Cable 100Mbps: Cat 5,5E Unshielded Cable

1000Mbps: Cat 5E, 6 Unshielded Cable

Pass Through Data Rates

10/100/1000 Mbps

Power Output

Adjustable 5Vdc 3A, 9Vdc 2.5A, 12Vdc 2.5A, 18Vdc 1.6A.

Input Power Requirements

DC Input Voltage: 36 to 57 Vac

Indicators

PoE ready / in-use

Connectors

Shielded RJ-45, EIA 568A and 568B

Dimensions

78x73x28mm

Environmental Conditions

Operating Ambient Temperature:0 to 40℃ Operating Humidity:

Maximum 90%, Non-condensing Storage Temperature:-20 to 70℃ Storage Humidity:

Maximum 95%, Non-condensing

Regulatory Compliance

IEEE 802.3af/at (PoE) IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet) IEEE 802.3ab (Gigabit Ethernet)

RoHS Compliant, CE, FCC

Electromagnetic

FCC Part15, Class B
